TOA PC-1860BS Ceiling Speaker

The TOA PC-1860BS Ceiling Speaker is a professional 6W 100V line ceiling speaker designed for public address (PA), background music (BGM), voice evacuation, and emergency communication systems. Its sleek flat-panel design blends naturally with modern interiors, making it an excellent choice for offices, hotels, shopping malls, public buildings, and commercial facilities.

Designed with safety and reliability in mind, the PC-1860BS features a robust steel fire dome that helps prevent the spread of fire through ceiling spaces. The speaker complies with BS 5839-8:2013 and EN54-24 standards, making it suitable for use in voice alarm and emergency evacuation applications.

Equipped with a 12 cm high-sensitivity cone speaker, the PC-1860BS delivers clear and consistent audio with a sensitivity of 95 dB. Its 100V/70V line transformer provides multiple power tapping options, allowing flexible configuration for different PA system requirements.

For enhanced safety and durability, the speaker includes a ceramic screw terminal block and thermal fuse. Its quick and convenient installation design makes it suitable for professional ceiling audio installations.

Key Features

• 6W 100V line ceiling speaker
• Suitable for PA, BGM, paging, and voice evacuation systems
• 12 cm high-sensitivity cone speaker
• High sensitivity of 95 dB for clear audio
• Maximum SPL of 100 dB at 1m
• Fire-rated steel dome for enhanced safety
• Compliant with BS 5839-8:2013
• EN54-24 compliant
• Multiple 100V/70V line power tapping options
• Ceramic screw terminal block
• Built-in thermal fuse for protection
• Sleek and modern flat front panel
• Quick and easy ceiling installation
• IP21C protection rating
• Durable steel construction with RAL 9016 white finish

Technical Specifications

• Rated Input: 6W
• Speaker Type: 12 cm cone-type
• Line Voltage: 100V / 70V
• Sensitivity: 95 dB
• Maximum SPL: 100 dB (1m)
• Frequency Response: 170 Hz – 20 kHz
• Impedance: 100V / 70V line with multiple tapping options
• Protection Rating: IP21C
• Material: Steel
• Finish: RAL 9016 White
• Dimensions: Ø180 × 105 mm
• Operating Temperature: -10°C to +50°C
• Safety Standards: BS 5839-8:2013 / EN54-24
